WTE210 excavator has become a leader in the excavator market with its powerful power system, efficient hydraulic system, rugged and durable structural design, comfortable driving environment, wide range of applications and environmentally friendly emission performance, meeting the diverse needs of different customers.
| Total weight | 21,800 kg |
|---|---|
| Rated bucket capacity | 1.0 m³ |
| Engine brand | ISUZU |
| Output power | 113.2 kW / 2100 rpm |
Four filter elements and pilot solenoid valves are centrally arranged, with all filters accessible for replacement and maintenance while the machine remains on the ground, offering exceptional convenience.
Using Isuzu 6BG1 engines, high power and high performance of core components, it continues to maintain Maintaining the performance advantages of the previous generation product; the engine cylinder combustion temperature is high, the fuel efficiency is significantly improved, and the power is strong; the exhaust gas emissions are environmentally friendly.
The central rotary motor adopts a well-known foreign brand with stable performance and durability.
| Model | WTE210 |
|---|---|
| Machine type | Medium mining hydraulic excavator |
| Operating weight | 21,800 kg |
| Bucket capacity | 1.0 m³ |
| Engine brand | Isuzu |
| Rated power | 113.2 kW / 2,100 rpm |
| Max. digging depth | 6,750mm |
| Max. digging reach | 9,940 mm |
| Max. digging force (bucket) | 193 kN |
| Travel speed | 4.9 / 3.2 km/h |
| Swing speed | 11.8 rpm |
| Fuel tank capacity | 370 L |
| Hydraulic system pressure | 31.4 MPa |
| Overall dimensions (L×W×H) | 9,570 × 2,800 × 2,970 mm |
| Emission standard | China IV / Euro V (optional) |
WISASTA — premium construction & mining machinery.
WISASTA — premium construction & mining machinery.
Review job-site suitability, lead time, after-sales coverage and configuration flexibility in one consolidated overview before you request a formal quotation.
Ideal for landscaping, municipal maintenance, agriculture and narrow-access projects. Compact footprint delivers stable, reliable control.
Lead time varies by order quantity and unit configuration. Standard configurations ship faster, while custom-spec machines require extended production and QC procedures.
Support package includes remote troubleshooting, maintenance guidance and critical spare-parts coordination to minimize unexpected downtime.
Attachments and selected specifications can be tailored to local compliance standards, operator preferences and project requirements.
Need landed cost, ETA and attachment recommendations? Share your project details to receive a faster, more accurate quotation.
